Tech Specs — iPhone 17 Pro Max

Display

• Super Retina XDR display

• 6.9-inch (diagonal) all-screen OLED display

• 2868-by-1320-pixel resolution at 460 ppi

• The iPhone 17 Pro Max display has rounded corners that follow a curved design, and these corners are within a standard rectangle. When measured as a standard rectangular shape, the screen is 6.86 inches diagonally (actual viewable area is less)

• Dynamic Island

• Always-On display

• ProMotion technology with adaptive refresh rates up to 120Hz

• HDR display

• True Tone

• Wide color (P3)

• Haptic Touch

• 2,000,000:1 contrast ratio (typical)

• 1000 nits max brightness (typical)

• 1600 nits peak brightness (HDR)

• 3000 nits peak brightness (outdoor)

• 1 nit minimum brightness

• Fingerprint-resistant oleophobic coating

• Anti-reflective coating

• Support for display of multiple languages and characters simultaneously

Chip

• A19 Pro chip

• 6-core CPU with 2 performance and 4 efficiency cores

• 6-core GPU with Neural Accelerators

• 16-core Neural Engine

• Hardware-accelerated ray tracing

• Apple Intelligence

Camera

• 48MP Pro Fusion camera system

• 48MP Fusion Main: 24 mm, ƒ/1.78 aperture

• Second-generation sensor-shift optical image stabilization

• 100% Focus Pixels

• Support for super-high-resolution photos (24MP and 48MP)

• Also enables 12MP optical-quality 2x Telephoto: 48 mm, ƒ/1.78 aperture

• Second-generation sensor-shift optical image stabilization

• 100% Focus Pixels

• 48MP Fusion Ultra Wide: 13 mm, ƒ/2.2 aperture

• 120° field of view

• Hybrid Focus Pixels

• Super-high-resolution photos up to 48MP

• 48MP Fusion Telephoto: 100 mm (4x), ƒ/2.8 aperture

• Hybrid Focus Pixels

• 3D sensor-shift optical image stabilization and autofocus

• Tetraprism design

• Also enables 12MP optical-quality 8x Telephoto: 200 mm, ƒ/2.8 aperture

• Hybrid Focus Pixels

• 3D sensor-shift optical image stabilization and autofocus

• Tetraprism design

• 8x optical-quality zoom in

• 2x optical zoom out

• 16x optical-quality zoom range

• Digital zoom up to 40x

• Customizable default lens (Fusion Main)

• Sapphire crystal lens cover

• Adaptive True Tone flash

• Photonic Engine

• Deep Fusion

• Smart HDR 5

• Next-generation portraits with Focus and Depth Control

• Portrait Lighting with six effects

• Night mode

• Panorama up to 63MP

• Latest-generation Photographic Styles

• Spatial photos

• 48MP macro photography

• ProRAW

• Wide color capture for photos and Live Photos

• Lens correction (Fusion Ultra Wide)

• Advanced red-eye correction

• Auto image stabilization

• Burst mode

• Photo geotagging

• Image formats captured

Video Recording

• 4K Dolby Vision video recording at 24 fps, 25 fps, 30 fps, 60 fps, 100 fps (Fusion Main), or 120 fps (Fusion Main)

• 1080p Dolby Vision video recording at 25 fps, 30 fps, 60 fps, or 120 fps (Fusion Main)

• 720p Dolby Vision video recording at 30 fps

• Cinematic mode up to 4K Dolby Vision at 30 fps

• Action mode up to 2.8K Dolby Vision at 60 fps

• Spatial video recording at 1080p at 30 fps

• ProRes video recording up to 4K at 120 fps with external recording

• ProRes RAW

• Academy Color Encoding System

• Apple Log 2

• Genlock support

• Macro video recording, including slo-mo and time-lapse

• Slo-mo video support for 1080p up to 240 fps

• 4K Dolby Vision slo-mo up to 120 fps using Fusion Main

• Dual Capture up to 4K Dolby Vision at 30 fps

• Time-lapse video with stabilization

• Night mode Time-lapse

• QuickTake video up to 4K Dolby Vision at 60 fps

• Second-generation sensor-shift optical image stabilization for video (Fusion Main)

• 3D sensor-shift optical image stabilization and autofocus for video (Fusion Telephoto)

• Digital zoom up to 15x

• Audio zoom

• True Tone flash

• Cinematic video stabilization (4K, 1080p, and 720p)

• Continuous autofocus video

• Take 8MP still photos while recording 4K video

• Playback zoom

• Video formats recorded: HEVC, H.264, ProRes, and ProRes RAW

• Spatial Audio and stereo recording

• Four studio-quality microphones

• Wind noise reduction

• Audio Mix

Front Camera

• 18MP Center Stage camera

• ƒ/1.9 aperture

• Autofocus with Focus Pixels

• Retina Flash

• Tap to zoom and rotate

• Center Stage for photos

• Ultra-stabilized video

• Dual Capture

• Center Stage for video calls

• Photonic Engine

• Deep Fusion

• Smart HDR 5

• Next-generation portraits with Focus and Depth Control

• Portrait Lighting with six effects

• Animoji and Memoji

• Night mode

• Latest-generation Photographic Styles

• ProRAW

• Wide color capture for photos and Live Photos

• Lens correction

• Auto image stabilization

• Burst mode

• 4K Dolby Vision video recording at 24 fps, 25 fps, 30 fps, or 60 fps

• 1080p Dolby Vision video recording at 25 fps, 30 fps, or 60 fps

• Cinematic mode up to 4K Dolby Vision at 30 fps

• ProRes video recording up to 4K at 60 fps with external recording

• ProRes RAW

• Academy Color Encoding System

• Apple Log 2

• Slo-mo video support for 1080p at 120 fps

• Time-lapse video with stabilization

• Night mode Time-lapse

• QuickTake video up to 4K at 60 fps in Dolby Vision

• Cinematic video stabilization (4K, 1080p, and 720p)

• Spatial Audio and stereo recording

• Wind noise reduction

• Audio Mix

Face ID

• Enabled by TrueDepth technology in the Center Stage front camera

Splash, Water, and Dust Resistant

• Rated IP68

• Maximum depth of 6 meters for up to 30 minutes

• Tested under IEC standard 60529

Action Button Features

• Silent Mode

• Focus

• Camera

• Visual Intelligence

• Flashlight

• Voice Memo

• Recognize Music

• Translate

• Magnifier

• Controls

• Shortcut

• Accessibility

Camera Controls

• Exposure

• Depth

• Zoom

• Cameras

• Styles

• Tone

Storage

• 128GB

• 256GB

• 512GB

• 1TB

Size and Weight

• Width: 78.0 mm

• Height: 163.4 mm

• Depth: 8.75 mm

• Weight: 233 grams

Battery

• Built-in rechargeable lithium-ion battery

• Video playback: up to 39 hours

• Video playback (streamed): up to 35 hours

• Fast-charge capable

• Up to 50% charge in 20 minutes with a 40W adapter or higher and USB-C charging cable

• Up to 50% charge in 30 minutes with a 30W adapter or higher using MagSafe Charger

Connectivity

• 5G

• 5G sub-6 GHz and mmWave depending on model

• 4×4 MIMO

• Gigabit LTE

• Apple N1 wireless networking chip

• Wi-Fi 7 (802.11be) with 2×2 MIMO

• Bluetooth 6

• Thread networking technology

• Second-generation Ultra Wideband chip

• NFC with reader mode

• Express Cards with power reserve

Location

• Precision dual-frequency GPS

• GPS

• GLONASS

• Galileo

• QZSS

• BeiDou

• NavIC

• Digital compass

• Wi-Fi

• Cellular

• iBeacon microlocation Apple Support

Charging and Expansion

• USB-C connector

• Charging

• DisplayPort

• USB 3 up to 10Gb/s

• MagSafe wireless charging up to 25W

• Qi2 wireless charging up to 25W

• Magnet array

• Alignment magnet

• Accessory Identification NFC

• Magnetometer

Sensors

• Face ID

• LiDAR Scanner

• Barometer

• High dynamic range gyro

• High-g accelerometer

• Proximity sensor

• Dual ambient light sensors

Design

• Aluminum unibody design

• Ceramic Shield 2 front

• Ceramic Shield back

• Available in:

  • Silver

  • Cosmic Orange

  • Deep Blue

Apple Intelligence

• Apple Intelligence integrated across apps and experiences

• Writing Tools

• Image Playground

• Genmoji

• Visual Intelligence

• Live Translation and other Apple Intelligence features, subject to language and regional availability Apple

Key differences from iPhone 17 Pro

The 17 Pro Max has the same A19 Pro chip and Pro camera system as the 17 Pro, but the major hardware differences are:

• 6.9-inch display instead of 6.3-inch

• 2868 × 1320 resolution instead of 2622 × 1206

• Up to 39 hours video playback instead of 33 hours

• 233 g instead of 206 g

• Same 48MP Pro Fusion camera system and 8x optical-quality telephoto capability
